Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems

Certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
I'm Online Chat Now

Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems

Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems
Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems

Large Image :  Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems

Product Details:
Place of Origin: China
Brand Name: Shenzhou Anfu
Certification: ISO ,Test Report
Model Number: AF69
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: US$42-55/pc
Packaging Details: one piece to a small box , 10pcs to a carton box
Delivery Time: 2-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000-40000/Month

Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems

Description
Interface: USB Charging Port Color: Blue, Customized
Storage Capacity: 16GB Exceptional Functions: Supports For All Types Of Payment
Nfc: Yes Touch: Resistive Touch Screen
Type: Thermal Printer Lcd: 1.7" IPS Screen, 128x64
Operating System: RTOS ,LINUX Card Support: Visa, Mastercard
High Light:

RTOS Operating Systems Handheld POS Terminal

,

RTOS Handheld POS Terminal

,

Linux 5.4 Handheld POS Terminal

Linux 5.4 and RTOS Operating Systems The Power Behind Our Handheld POS Terminal





Company Profile:





Welcome to Beijing Shenzhou Anfu Company, a cutting-edge facility at the forefront of technological innovation in security SOC chips and modules. Our factory boasts state-of-the-art equipment and facilities optimized for precision engineering and advanced manufacturing processes. Leveraging 32-bit embedded high-performance CPU SOC chip design platforms, we pioneer groundbreaking solutions in information security, mobile payment, and beyond.

At Shenzhou Anfu, we prioritize research and development, investing heavily in proprietary technologies to maintain our position as leaders in the industry. With a strong focus on intellectual property, we hold numerous patents and copyrights, underlining our commitment to innovation and excellence.

Our team of skilled professionals is dedicated to pushing the boundaries of what's possible, continuously striving for breakthroughs in product design, development, and industrialization. By adhering to rigorous quality management standards and implementing stringent protocols, we ensure that every product leaving our factory meets the highest standards of performance and reliability.

Join us at Beijing Shenzhou Anfu Company, where technology meets innovation to shape the future of security encryption and intelligent terminal solutions.





Specification:



Operating System Linux 5.4
RTOS
Processor Linux:Cortex-A7 1.2 GHz
RTOS:Cortex-A5 500MHz
Memory Linux:256MB Flash + 128MB RAM
RTOS:8MB Flash + 16MB RAM
Card Readers MSR: ISO7810-7813, 3 tracks
IC Card: ISO7816
NFC Reader 13.56MHz, ISO/IEC14443 TypeA&B,
Camera Rear camera:0.3 million pixels
Display 2.4" 320x240 TFT
Resistive Touch Screen
Wireless Communication Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS)
RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS)
Battery Li-ion battery 3.7V/2000mAh
Card Slots
SIM / SAM
SIM Card x 2
Keypad Numeric x 10
Function x 5
Power x 1
Audio 1 Buzzer
Ports Linux:1 Type-C USB OTG | USB 2.0
RTOS:11 Type-C | USB 2.0
Indicator lights 4 Work indicator lights
Adapter Input: AC 100-240V, 50/60Hz
Output: 5V/1A
Scanning charging base Printer charging base(optional)
Weight 160g
Dimensions 123(L) x 70(W) x 17(H) mm
Environment Storage temperature: -20°C to 60°C
Operating temperature: -10°C to 50°C
Humidity: ≤95%
Certifications EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass
PCI PTS 6.x / TQM / CE

Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems 0Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems 1

Product Feature

Beijing Shenzhou Anfu Technology Co.,Ltd is a high-tech enterprise engaged in financial payment terminal products, It is committed to product research and development, system integration and technical services in the field of safe payment, providing mobile payment products of international advanced level, offline payment
Advantages
● It supports 4G/3G/2G networking
● It supports the internet sharing function of mobile phone Bluetooth
● It supports handling of magnetic stripe card , contact IC card and non - contact IC card
● It supports NFC payment of mobile phone such as Apple Pay , etc .
● It supports QR code payment of WeChat , Alipay , Quick Pass , etc .
● It supports electronic signature receipt and paperless management
● Configured with camera to support the dual modes of main Scanning and being Scanned
● With attack - detection mechanism , multiple anti - disassembly and self - destruction mechanism
● It meets the latest safety certification standard of UnionPay
● The base has charging function
●The base is a dedicated Bluetooth printer for AF69 products

Real Case for Lower MOQ:

Products Name MOQ(in the last 12month)
POS Device 5 Pieces

The competitive advantage of product line:

Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.



Certificate



Advanced Handheld POS Terminal With Linux 5.4 And RTOS Operating Systems 2



FAQ



1. Q: How can I get the touch pos terminal sample to check quality?

After price comfirmation, you can order pos samples to check quality.

Contact:whatsapp +86 18011965815



2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,



3. Q: How can I become your agent?

A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.



4. Q: Who will pay the postage of the returns?

A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)



5. Q:What is your warranty?

We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
