Product Details:
|
Warranty: | 1 Year | Exceptional Functions: | Supports For All Types Of Payment |
---|---|---|---|
Programmable: | Support Secondary Development | Connectivity: | 3G, 4G, Wi-Fi, Bluetooth |
Security: | PCI PTS 5.x Certified | System: | Supports Linux RTOS Operating System |
Keyboard: | Digital Button | Main Screen: | 2.4 |
High Light: | Contactless Payment MPOS Terminal,Contactless Payment Options MPOS Terminal,Contact MPOS Terminal |
EMV Certified MPOS Terminal with Contact and Contactless Payment Options for Security
Specification:
Operating System | Linux 5.4 RTOS |
Processor | Linux:Cortex-A7 1.2 GHz RTOS:Cortex-A5 500MHz |
Memory | Linux:256MB Flash + 128MB RAM RTOS:8MB Flash + 16MB RAM |
Card Readers | MSR: ISO7810-7813, 3 tracks IC Card: ISO7816 |
NFC Reader | 13.56MHz, ISO/IEC14443 TypeA&B, |
Camera | Rear camera:0.3 million pixels |
Display | 2.4" 320x240 TFT Resistive Touch Screen |
Wireless Communication | Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS) RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS) |
Battery | Li-ion battery 3.7V/2000mAh |
Card Slots SIM / SAM |
SIM Card x 2 |
Keypad | Numeric x 10 Function x 5 Power x 1 |
Audio | 1 Buzzer |
Ports | Linux:1 Type-C USB OTG | USB 2.0 RTOS:11 Type-C | USB 2.0 |
Indicator lights | 4 Work indicator lights |
Adapter | Input: AC 100-240V, 50/60Hz Output: 5V/1A |
Scanning charging base | Printer charging base(optional) |
Weight | 160g |
Dimensions | 123(L) x 70(W) x 17(H) mm |
Environment | Storage temperature: -20°C to 60°C Operating temperature: -10°C to 50°C Humidity: ≤95% |
Certifications | EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass PCI PTS 6.x / TQM / CE |
Company Information
Meet Anfu – a trailblazing individual with a passion for innovation and a drive for excellence. Hailing from Beijing, Anfu is not just a person but a visionary leader at the helm of Shenzhou Anfu Company.
Anfu's journey is one of determination and ingenuity. Rising from humble beginnings, they embarked on a quest to revolutionize the world of security technology. With each challenge they faced, Anfu emerged stronger, armed with a relentless pursuit of knowledge and a thirst for innovation.
As the founder of Shenzhou Anfu Company, Anfu has cultivated a culture of creativity and collaboration. They believe in pushing the boundaries of what's possible, constantly striving to stay ahead of the curve in an ever-evolving industry.
But Anfu's impact extends far beyond the walls of their company. They are a mentor, a visionary, and a driving force for change in the world of technology. Whether it's mentoring young talent or forging partnerships with industry leaders, Anfu's influence is felt far and wide.
In a world where technology shapes our future, Anfu stands as a beacon of inspiration – a reminder that with passion, perseverance, and a commitment to excellence, anything is possible. So let's raise a toast to Anfu – a true pioneer in the world of security technology.
Beijing Shenzhou Anfu Technology Co.,Ltd is a high-tech enterprise engaged in financial payment terminal products, It is committed to product research and development, system integration and technical services in the field of safe payment, providing mobile payment products of international advanced level, offline payment
Advantages
● It supports 4G/3G/2G networking
● It supports the internet sharing function of mobile phone Bluetooth
● It supports handling of magnetic stripe card , contact IC card and non - contact IC card
● It supports NFC payment of mobile phone such as Apple Pay , etc .
● It supports QR code payment of WeChat , Alipay , Quick Pass , etc .
● It supports electronic signature receipt and paperless management
● Configured with camera to support the dual modes of main Scanning and being Scanned
● With attack - detection mechanism , multiple anti - disassembly and self - destruction mechanism
● It meets the latest safety certification standard of UnionPay
● The base has charging function
●The base is a dedicated Bluetooth printer for AF69 products
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
