Product Details:
|
Memory: | RTOS:8MB Flash + 16MB RAM | Warranty: | 3 Months |
---|---|---|---|
Battery: | 3.7V/2500mAh | 3.7V/3200mAh (optional) | Weight: | 297g |
Connectivity: | Wi-Fi, Bluetooth, USB | Display Type: | LCD |
Model No: | AF75 | Security: | PCI PTS 6.x Certified |
High Light: | handheld Smart Mobile POS Terminal,Smart Mobile POS Terminal |
Company Information
Beijing Shenzhou Anfu Technology Co., Ltd. has a commendable track record since its inception in 2015. The company has diligently catered to users across various sectors including government, finance, energy, and transportation. Its offerings span a comprehensive range of information security products, holistic security solutions, and user-friendly financial payment services.
Shenzhou Anfu's ethos revolves around prioritizing user needs and fostering independent innovation. This commitment is evident in its three distinct product segments: financial technology, information security, and system platform. By embracing the ethos of independent innovation and embodying the corporate spirit of focus and professionalism, the company operates on the pillars of quality, efficiency, collaboration, and mutual benefit.
Guided by customer demand and experiences, Shenzhou Anfu continuously refines and innovates its products. It upholds stringent standards in production quality and consistently enhances the quality and competitiveness of its integrated services. The company aspires to ascend as a premier domestic provider of information security and financial technology solutions, driven by its unwavering dedication to serving users and pioneering innovation.
Specification
Operating System | Linux 5.4 RTOS |
Processor | Linux:Cortex-A7 1.2 GHz RTOS:Cortex-A5 500MHz |
Memory | Linux:256MB Flash + 128MB RAM RTOS:8MB Flash + 16MB RAM |
Card Readers | MSR: ISO7810-7813, 3 tracks IC Card: ISO7816 |
NFC Reader | 13.56MHz, ISO/IEC14443 TypeA&B, |
Camera | Rear camera:0.3 million pixels |
Display | 2.8" 320x240 TFT Resistive Touch Screen |
Wireless Communication | Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS) RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS) |
Battery | emovable Lithium polymer battery, 3.7V/2500mAh | 3.7V/3200mAh (optional) |
Printer | Print Speed:30 lines/s Paper Roll: 58*40mm |
Card Slots SIM / SAM |
SIM Card x 2 + PSAM X 1 |
Positioning | X |
Keypad | Numeric x 10 Function x 8 Power x 1 |
Audio | 1 Buzzer |
Ports | Linux:1 Type-C USB OTG | USB 2.0 RTOS:11 Type-C | USB 2.0 |
Indicator lights | 4 Work indicator lights |
Adapter | Input: AC 100-240V, 50/60Hz Output: 5V/1A |
Scanning charging base | X |
Weight | 297g |
Dimensions | 165(L) x 79(W) x56(H) mm |
Environment | Storage temperature: -20°C to 60°C Operating temperature: -10°C to 50°C Humidity: ≤95% |
Certifications | EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass PCI PTS 6.x / TQM / CE |
SMARTPOS--AF820
The latest Android13 system, the system is smoother
4.0-inch color screen, more convenient to use
External digital installation, safer payment
Printing, scanning code, card payment are fully!supported
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
