Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified

Certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
I'm Online Chat Now

Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified

Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified
Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified

Large Image :  Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified

Product Details:
Place of Origin: China
Brand Name: Shenzhou Anfu
Certification: ISO,Test Report
Model Number: AF75
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: US$45-55/pc
Packaging Details: one piece to a small box , 10pcs to a carton box
Delivery Time: 2-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000-40000/Month

Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified

Description
Item: Mobile Wireless Payment Terminal Paper Width: 58mm
Wifi: WIFI 802.11b/g/n (2.4G) Network: 2G,/3G, 4G,Wifi, Bluetooth,GPS,NFC
Smart Cash Register: Payment Pos Terminal Sdk: Provided
Connection: Blue Tooth Size: 177mm*81mm*56mm
High Light:

2.8"TFT Mobile pos terminal

,

EMV Mobile pos terminal

,

58mm Mobile pos terminal

Mobile 2.8"TFT display handheld traditional pos terminal with 58mm thermal printer EMV certified



Company Information

In today's hyper-connected world, businesses face unprecedented challenges in safeguarding their data and staying ahead in the rapidly evolving landscape of financial technology. From the constant threat of cyber attacks to the need for seamless payment solutions, the demands on businesses are greater than ever before.

The Challenge:
Businesses across industries grapple with the daunting task of protecting their sensitive information from ever-evolving cyber threats. With the proliferation of data breaches and security vulnerabilities, the stakes have never been higher. Additionally, in the realm of financial technology, businesses face the dual challenge of ensuring secure transactions while keeping pace with the demands of digital payment ecosystems.

The Solution: Anfu
Enter Anfu, a leader in information security and financial technology solutions. Since its inception in 2015, Anfu has been dedicated to addressing the pressing challenges faced by businesses today.

Information Security Solutions:
Anfu offers a comprehensive suite of information security products and services designed to safeguard businesses against cyber threats. From robust firewall solutions to advanced encryption technologies, Anfu provides the tools businesses need to protect their data and mitigate risks effectively.

Financial Technology Solutions:
In the realm of financial technology, Anfu's innovative solutions empower businesses to navigate the complexities of digital transactions with ease and confidence. Whether it's secure online payment gateways or cutting-edge blockchain technology, Anfu delivers solutions that streamline financial processes and enhance operational efficiency.

The Anfu Advantage:
What sets Anfu apart is not just its advanced technology but also its commitment to customer satisfaction and service excellence. With a team of dedicated experts and a customer-centric approach, Anfu works closely with businesses to understand their unique needs and provide tailored solutions that drive success.

Conclusion:
In an era defined by digital transformation and heightened security risks, Anfu stands as a beacon of reliability and innovation. By offering comprehensive solutions to today's most pressing challenges, Anfu empowers businesses to thrive in a rapidly changing world.



Specification





Operating System Linux 5.4
RTOS
Processor Linux:Cortex-A7 1.2 GHz
RTOS:Cortex-A5 500MHz
High performance 32-bit security CPU
Memory Linux:256MB Flash + 128MB RAM
RTOS:8MB Flash + 16MB RAM
Card Readers MSR: ISO7810-7813, 3 tracks
IC Card: ISO7816
NFC Reader 13.56MHz, ISO/IEC14443 TypeA&B,
Camera Rear camera:0.3 million pixels
Display 2.8" 320x240 TFT
Resistive Touch Screen
Wireless Communication Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS)
RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS)
Battery emovable Lithium polymer
battery, 3.7V/2500mAh | 3.7V/3200mAh (optional)
Printer High speed thermal printing, printing lifeis not less than 50km
The specification is 58mm in width and 40mm in diameter
Card Slots
SIM / SAM
SIM Card x 2 + PSAM X 1
Positioning X
Keypad Numeric x 10
Function x 8
Power x 1
Audio 1 Buzzer
Ports Linux:1 Type-C USB OTG | USB 2.0
RTOS:11 Type-C | USB 2.0
Indicator lights 4 Work indicator lights
Adapter Input: AC 100-240V, 50/60Hz
Output: 5V/1A
Scanning charging base X
Weight 340g
Physical size 177mm*81mm*56mm
Environment Storage temperature: -20°C to 60°C
Operating temperature: -10°C to 50°C
Humidity: ≤95%
Certifications EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass
PCI PTS 6.x / TQM / CE
Display 2.8"(320 x 240)TFT, resistive touch screen
WlFl(optional) 802.11 a/b/g/n,2.4G
Mobile communication Linux:4G CAT4,WCDMA,GSM
RTOS:4G CAT1,GSM
South American Version
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;
TDD-LTE:B40
GSM:B2/B3/B5/B8
European Version
FDD-LTE:B1/B3/B5/B7/B8/B20;
TDD-LTE:B38/B40/B41
GSM:B3/B8
Contact lC card Comply with lS0 7816 and China financial
integrated circuit (lC) card specification;
The card holder can be used for more than300000 times
Magnetic stripe card Support three track data reading;
It supports two-way card swiping.
The swipingspeed ranges from 10 cm /s to 100 cm /s.
The service life of the magnetic stripe reader canreach more than 400000 times;
It conforms to iso78ll and iso7812 standards
RTC Built in RTC to save the clock; Buttonbattery life > 5 years



Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified 0

Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified 1



Product Feature

SMARTPOS--AF820


The latest Android13 system, the system is smoother


4.0-inch color screen, more convenient to use


External digital installation, safer payment


Printing, scanning code, card payment are fully!supported



Real Case for Lower MOQ:

Products Name MOQ(in the last 12month)
POS Device 5 Pieces

The competitive advantage of product line:

Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.



Certificate



Mobile 2.8"TFT Display Handheld Traditional Pos Terminal With 58mm Thermal Printer EMV Certified 2



FAQ



1. Q: How can I get the touch pos terminal sample to check quality?

After price comfirmation, you can order pos samples to check quality.

Contact:whatsapp +86 18011965815



2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,



3. Q: How can I become your agent?

A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.



4. Q: Who will pay the postage of the returns?

A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)



5. Q:What is your warranty?

We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
