Product Details:
|
Interface: | USB | Ability: | 20000-40000 Sets/Month |
---|---|---|---|
Operating System: | LINUX RTOS | Charging Base: | Input :AC100-240 |
Card Reader: | Magnetic Stripe, EMV, NFC | Google Pay Store: | Support |
Is Customized: | Yes | Payment Currency: | USD, EUR, CNY |
High Light: | Password Pin Pad Mobile POS Pinpad,AF75 Mobile POS Pinpad,Numeric Keyboard Mobile POS Pinpad |
Company Information
Shenzhou Anfu is a pioneering force in the realm of security technology, specializing in SOC chips and modules, as well as the design, development, and distribution of security terminal products. Recognized as a high-tech enterprise, Shenzhou Anfu has garnered prestigious certifications including the national high-tech enterprise certification, UnionPay card acceptance terminal product enterprise certification, software enterprise certification, and IS9001:2015 quality management system certification. Notably, it holds the distinction of being a designated production and sales unit for commercial password products sanctioned by the State Password Administration.
At the core of Shenzhou Anfu's operations is a steadfast commitment to cutting-edge research and development within the security domain. Leveraging a robust 32-bit embedded high-performance CPU SOC chip design platform, the company pioneers advancements in information security, mobile payment technologies, and other SOC chip products and application program design. Its comprehensive suite of offerings finds applications across diverse sectors including intelligent terminals, security protection products, smart homes, smart locks, financial payment systems, and specialized information encryption products.
A testament to its innovation prowess, Shenzhou Anfu boasts 14 independent intellectual property rights, encompassing 2 invention patents, 5 utility model patents, 4 appearance patents, and 9 software copyrights. Upholding a philosophy of independent research and development, the company channels substantial investments into product innovation and design annually. Noteworthy achievements include the successful serial production of AX200 chip products and the introduction of numerous industry-leading security solutions.
Driven by a fusion of leading-edge technology, data-driven decision-making processes, and rigorous standardization protocols, Shenzhou Anfu has ascended to eminence as a renowned enterprise within the security encryption domain. It serves as a trusted supplier of independent security chips, modules, and intelligent security terminals to clients spanning the security, banking and finance, e-government, and convenience services sectors both domestically and internationally.
Specification
Operating System | Linux 5.4 RTOS |
Processor | Linux:Cortex-A7 1.2 GHz RTOS:Cortex-A5 500MHz High performance 32-bit security CPU |
Memory | Linux:256MB Flash + 128MB RAM RTOS:8MB Flash + 16MB RAM |
Card Readers | MSR: ISO7810-7813, 3 tracks IC Card: ISO7816 |
NFC Reader | 13.56MHz, ISO/IEC14443 TypeA&B, |
Camera | Rear camera:0.3 million pixels |
Display | 2.8" 320x240 TFT Resistive Touch Screen |
Wireless Communication | Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS) RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS) |
Battery | emovable Lithium polymer battery, 3.7V/2500mAh | 3.7V/3200mAh (optional) |
Printer | High speed thermal printing, printing lifeis not less than 50km The specification is 58mm in width and 40mm in diameter |
Card Slots SIM / SAM |
SIM Card x 2 + PSAM X 1 |
Positioning | X |
Keypad | Numeric x 10 Function x 8 Power x 1 |
Audio | 1 Buzzer |
Ports | Linux:1 Type-C USB OTG | USB 2.0 RTOS:11 Type-C | USB 2.0 |
Indicator lights | 4 Work indicator lights |
Adapter | Input: AC 100-240V, 50/60Hz Output: 5V/1A |
Scanning charging base | X |
Weight | 340g |
Physical size | 177mm*81mm*56mm |
Environment | Storage temperature: -20°C to 60°C Operating temperature: -10°C to 50°C Humidity: ≤95% |
Certifications | EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass PCI PTS 6.x / TQM / CE |
Display | 2.8"(320 x 240)TFT, resistive touch screen |
WlFl(optional) | 802.11 a/b/g/n,2.4G |
Mobile communication | Linux:4G CAT4,WCDMA,GSM RTOS:4G CAT1,GSM South American Version FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B; TDD-LTE:B40 GSM:B2/B3/B5/B8 European Version FDD-LTE:B1/B3/B5/B7/B8/B20; TDD-LTE:B38/B40/B41 GSM:B3/B8 |
Contact lC card | Comply with lS0 7816 and China financial integrated circuit (lC) card specification; The card holder can be used for more than300000 times |
Magnetic stripe card | Support three track data reading; It supports two-way card swiping. The swipingspeed ranges from 10 cm /s to 100 cm /s. The service life of the magnetic stripe reader canreach more than 400000 times; It conforms to iso78ll and iso7812 standards |
RTC | Built in RTC to save the clock; Buttonbattery life > 5 years |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
