Product Details:
|
Width: | 58mm | Interface: | USB/Blue-tooth/wifi |
---|---|---|---|
Touch Panel: | Resistive Touch Screen | Customized: | Supported |
Max Paper Size: | 58MM | Connection: | 2G 4G WIFI |
Nfc: | Optional And Support | Software: | SDK |
High Light: | Mobile Pos Wireless Pos System,4G Wi-Fi Point of Sale System,Portable Payment Machine Mobile Pos |
Company Information
I hope this message finds you well. I am excited to introduce you to Beijing Shenzhou Anfu Company, a pioneer in the field of security technology. Shenzhou Anfu is dedicated to providing top-notch security SOC chips, modules, and terminal products that are designed to meet the highest standards of performance and reliability.
At Shenzhou Anfu, we specialize in creating advanced security solutions that cater to a wide range of applications, including information security, mobile payments, smart homes, and more. Our commitment to excellence is reflected in the numerous certifications we have achieved, such as:
Our strength lies in our robust research and development capabilities. Utilizing a 32-bit embedded high-performance CPU SOC chip design platform, we develop cutting-edge solutions that set new benchmarks in the industry. We are proud to hold 14 independent intellectual property rights, including invention patents, utility model patents, appearance patents, and software copyrights.
Every year, we invest significantly in R&D to ensure we remain at the forefront of technological advancements. This dedication has led to the successful production of our AX200 chip series and the development of multiple industry-specific security solutions. Our products are widely trusted in sectors such as intelligent terminals, security protection, smart locks, financial payments, and specialized information encryption.
With leading technology, strategic decision-making, and standardized management, Shenzhou Anfu has grown into a renowned name in the security encryption field. We aim to be your trusted partner in providing secure, reliable, and innovative security solutions that safeguard your operations and enhance your business.
We would be delighted to explore how Shenzhou Anfu can support your security needs and contribute to your success. Please feel free to reach out to us for more information or to discuss potential collaboration opportunities.
Thank you for considering Shenzhou Anfu as your security technology partner. We look forward to the possibility of working together.
Specification
Operating System | Linux 5.4 RTOS |
Processor | Linux:Cortex-A7 1.2 GHz RTOS:Cortex-A5 500MHz High performance 32-bit security CPU |
Memory | Linux:256MB Flash + 128MB RAM RTOS:8MB Flash + 16MB RAM |
Card Readers | MSR: ISO7810-7813, 3 tracks IC Card: ISO7816 |
NFC Reader | 13.56MHz, ISO/IEC14443 TypeA&B, |
Camera | Rear camera:0.3 million pixels |
Display | 2.8" 320x240 TFT Resistive Touch Screen |
Wireless Communication | Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS) RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS) |
Battery | emovable Lithium polymer battery, 3.7V/2500mAh | 3.7V/3200mAh (optional) |
Printer | High speed thermal printing, printing lifeis not less than 50km The specification is 58mm in width and 40mm in diameter |
Card Slots SIM / SAM |
SIM Card x 2 + PSAM X 1 |
Positioning | X |
Keypad | Numeric x 10 Function x 8 Power x 1 |
Audio | 1 Buzzer |
Ports | Linux:1 Type-C USB OTG | USB 2.0 RTOS:11 Type-C | USB 2.0 |
Indicator lights | 4 Work indicator lights |
Adapter | Input: AC 100-240V, 50/60Hz Output: 5V/1A |
Scanning charging base | X |
Weight | 340g |
Physical size | 177mm*81mm*56mm |
Environment | Storage temperature: -20°C to 60°C Operating temperature: -10°C to 50°C Humidity: ≤95% |
Certifications | EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass PCI PTS 6.x / TQM / CE |
Display | 2.8"(320 x 240)TFT, resistive touch screen |
WlFl(optional) | 802.11 a/b/g/n,2.4G |
Mobile communication | Linux:4G CAT4,WCDMA,GSM RTOS:4G CAT1,GSM South American Version FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B; TDD-LTE:B40 GSM:B2/B3/B5/B8 European Version FDD-LTE:B1/B3/B5/B7/B8/B20; TDD-LTE:B38/B40/B41 GSM:B3/B8 |
Contact lC card | Comply with lS0 7816 and China financial integrated circuit (lC) card specification; The card holder can be used for more than300000 times |
Magnetic stripe card | Support three track data reading; It supports two-way card swiping. The swipingspeed ranges from 10 cm /s to 100 cm /s. The service life of the magnetic stripe reader canreach more than 400000 times; It conforms to iso78ll and iso7812 standards |
RTC | Built in RTC to save the clock; Buttonbattery life > 5 years |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
