Product Details:
|
Weight: | 340kgs | Cpu: | ARM Cortex-A5, Maximum Clock Frequency 500MHz |
---|---|---|---|
Operation System: | RTOS,LINUX | Shipment: | By Sea By Air By Express |
Customized: | Supported | Type: | Thermal Printer |
Connectivity: | WiFi, Bluetooth, 4G | Display Size: | 2.4 Inches |
High Light: | 4G NFC Handheld POS System,RTOS Handheld POS System,2.4 inches Handheld POS System |
Company Information
I am excited to introduce you to Beijing Shenzhou Anfu Technology Co., Ltd., a leading innovator in the field of security technology. Allow me to share why Shenzhou Anfu is the trusted name in security SOC chips, modules, and terminal products.
Beijing Shenzhou Anfu Technology Co., Ltd. (Shenzhou Anfu) is at the forefront of designing, developing, and selling state-of-the-art security solutions. Our expertise lies in creating advanced security SOC chips and modules, which are the backbone of various secure applications.
At Shenzhou Anfu, we believe in delivering only the best. Our commitment to quality and innovation is recognized through multiple prestigious certifications:
We specialize in foundational research and development in security technologies. Using a high-performance 32-bit embedded CPU SOC chip design platform, we focus on:
Our products are widely used in various sectors to enhance security and functionality:
Our commitment to innovation is evident in our 14 independent intellectual property rights, including:
This robust portfolio underscores our dedication to leading-edge technology and continuous improvement.
We invest heavily in independent research and development, enabling us to produce the AX200 chip series and numerous industry-specific security solutions. With advanced technology, scientific decision-making, and standardized management, Shenzhou Anfu has become a trusted name in security encryption, serving industries like banking, finance, e-government, and more.
We at Shenzhou Anfu are more than a technology provider; we are your partners in achieving security. Our innovative solutions ensure that your data, transactions, and information are protected by the best technologies available. We invite you to join us on our journey to a safer, more secure future.
For more information about our products and services, please feel free to contact us or visit our website. We look forward to working with you and providing the security solutions you need.
Specification
Function | Describe |
Processor | Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz |
Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency 96MHz |
|
Memory | Main CPU: 16MB Flash, 16MB RAM |
Display | 2.4 "(320 × 240) TFT, resistive touch screen |
RTC | Built in RTC to save the clock; Button battery life > 5 years |
Signature pen | Touch screen handwriting signature pen, plug-in |
Key |
20 physical keys: 1 power key, 12 digit / letter keys and 7 function keys,Cancel, clear, F1 / F2 / F3, menu) |
Contact IC card |
Comply with ISO 7816 and China financial integrated circuit (IC) card specification; The card holder can be used for more than 300000 times |
Contactless card |
13.56MHz; Support iso14443 type A & B standard; Qpboc compliant |
Magnetic stripe card
|
Support three track data reading; It supports two-way card swiping. The swiping speed ranges from 10 cm / s to 100 cm / s. The service life of the magnetic stripe reader can reach more than 400000 times; It conforms to iso7811 |
Camera(optional) |
Built in 300 megapixel camera Support bar code, two-dimensional code scanning |
Printer |
High speed thermal printing, printing life is not less than 50km The specification is 58mm in width and 40mm in diameter |
mobile communication |
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40 GSM:B2/B3/B5/B8 (Recommended: South America) |
FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41 GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa) |
|
Wifi(optional) | 802.11 a/b/g/n,2.4G |
Bluetooth (optional) | BLE 4.0 and above |
Card slots | 1 SIM + 2 SAMs | 2 SIMs + 1 SAM |
External interface | 1 TYPE-C USB,For charging and serial communication |
Battery(Optional) | 3.7V,2500mAh 3.7V,3000mAh |
Buzzer | Support |
Indication light | 1 power indicator + 4 contactless indicator |
Physical size | 177mm*81mm*56mm |
Weight | 340g |
Certificate |
PBOC3.0 L1&L2 EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED UPTS2.0 Security assessment of UnionPay terminal Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American ExpressPay SRRC/CTA/TQM3CCEBISWPC |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
