Product Details:
|
Physical Interface: | 1 Micro-USB Interface,1 IC Card Slot | Voice: | Built-in Speaker;Audio Playback |
---|---|---|---|
Function: | 3g/wifi/bluetooth/scanner/printer | Touch Screen Type: | Touch Screen |
Charging Base: | Input :AC100-240 | Buttons: | Power On/Off Button |
Battery: | 3.7V,2500mAh 3.7V,3000mAh | Monthly Supply Ability: | 20000 -40000Sets/Month |
High Light: | Supermarket Shop Handheld POS,2.4 inch Touch Screen Handheld POS,EMV Handheld POS |
Company Information
It is my pleasure to introduce you to Beijing Shenzhou Anfu Technology Co., Ltd., a pioneer in high-security technology solutions. Let’s delve into what makes Shenzhou Anfu a technological leader in the security industry.
At Shenzhou Anfu, technology is at the heart of everything we do. Our focus on innovation and advanced research drives the development of our state-of-the-art security SOC chips and modules. Here’s a closer look at our technological capabilities:
a. High-Performance SOC Chips:
b. Advanced Information Security Solutions:
c. Innovative Mobile Payment Technologies:
Our advanced technology solutions are applied across various sectors, enhancing security and performance:
a. Intelligent Terminals:
b. Security Protection Products:
c. Smart Home Devices:
d. Smart Locks:
e. Financial Payment Systems:
f. Special Information Encryption Products:
Innovation is the cornerstone of Shenzhou Anfu’s success. We hold 14 independent intellectual property rights, including:
These patents and copyrights highlight our commitment to developing proprietary technologies that set us apart in the security industry.
Our dedication to quality is reflected in our numerous certifications:
These certifications underscore our commitment to maintaining the highest standards in our technology and products.
At Shenzhou Anfu, we are more than a technology provider; we are your partners in achieving top-tier security. Our innovative technologies ensure that your data, transactions, and sensitive information are protected with the highest levels of security. Join us on our journey towards a safer, more secure future.
For more information about our advanced technology products and services, please contact us or visit our website. We look forward to working with you and providing the high-security solutions you need.
Specification
Function | Describe |
Processor | Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz |
Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency 96MHz |
|
Memory | Main CPU: 16MB Flash, 16MB RAM |
Display | 2.4 "(320 × 240) TFT, resistive touch screen |
RTC | Built in RTC to save the clock; Button battery life > 5 years |
Signature pen | Touch screen handwriting signature pen, plug-in |
Key |
20 physical keys: 1 power key, 12 digit / letter keys and 7 function keys,Cancel, clear, F1 / F2 / F3, menu) |
Contact IC card |
Comply with ISO 7816 and China financial integrated circuit (IC) card specification; The card holder can be used for more than 300000 times |
Contactless card |
13.56MHz; Support iso14443 type A & B standard; Qpboc compliant |
Magnetic stripe card
|
Support three track data reading; It supports two-way card swiping. The swiping speed ranges from 10 cm / s to 100 cm / s. The service life of the magnetic stripe reader can reach more than 400000 times; It conforms to iso7811 |
Camera(optional) |
Built in 300 megapixel camera Support bar code, two-dimensional code scanning |
Printer |
High speed thermal printing, printing life is not less than 50km The specification is 58mm in width and 40mm in diameter |
mobile communication |
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40 GSM:B2/B3/B5/B8 (Recommended: South America) |
FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41 GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa) |
|
Wifi(optional) | 802.11 a/b/g/n,2.4G |
Bluetooth (optional) | BLE 4.0 and above |
Card slots | 1 SIM + 2 SAMs | 2 SIMs + 1 SAM |
External interface | 1 TYPE-C USB,For charging and serial communication |
Battery(Optional) | 3.7V,2500mAh 3.7V,3000mAh |
Buzzer | Support |
Indication light | 1 power indicator + 4 contactless indicator |
Physical size | 177mm*81mm*56mm |
Weight | 340g |
Certificate |
PBOC3.0 L1&L2 EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED UPTS2.0 Security assessment of UnionPay terminal Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American ExpressPay SRRC/CTA/TQM3CCEBISWPC |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
