Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function

Certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
I'm Online Chat Now

Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function

Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function
Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function

Large Image :  Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function

Product Details:
Place of Origin: China
Brand Name: Shenzhou Anfu
Certification: ISO,Test Report
Model Number: AF70
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: US$45-55/pc
Packaging Details: one piece to a small box , 10pcs to a carton box
Delivery Time: 2-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000-40000/Month

Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function

Description
Exceptional Functions: Supports For All Types Of Payment Cpu: ARM Cortex-A5, Maximum Clock Frequency 500MHz
Barcode Recognition: Suppor 1D 2D Customize: Yes
Products Status: Stock Battery Capacity: 3.7V,2500mAh 3.7V,3000mAh
Currency: USD.EURO.CNY Max Paper Size: 58mm

Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with POS systems



Company Information

Unlocking the Future: The Shenzhou Anfu Journey

Imagine a world where your security is as seamless as a fingerprint, where every transaction is shielded by an invisible fortress, and your digital life is safeguarded by technology so advanced, it feels like magic. Welcome to Shenzhou Anfu – where cutting-edge innovation meets unwavering trust.

Who We Are: At the heart of Beijing, Shenzhou Anfu stands as a beacon of excellence in the realm of security technology. Our mission is simple yet profound: to protect what matters most to you with unparalleled precision and reliability.

Our Credentials: Certified and celebrated, Shenzhou Anfu is recognized as a National High-Tech Enterprise. We proudly hold the ISO 9001:2015 certification, among other prestigious accolades, underscoring our commitment to quality and innovation.

Innovation at Our Core: Dive into our world, built on a foundation of relentless research and development. Our 32-bit embedded high-performance CPU SOC chip design platform is not just technology – it’s the future of security. From information security to mobile payments, our SOC chip products are designed to meet the demands of a fast-evolving digital landscape.

Versatile and Visionary: Our products find homes in smart locks, intelligent terminals, financial payment systems, and more. Imagine your home, your transactions, and your data, all protected by Shenzhou Anfu’s cutting-edge technology. We don't just create products; we create peace of mind.

Intellectual Prowess: With 14 independent intellectual property rights, including invention and utility model patents, our innovations speak for themselves. Each product is a testament to our dedication to independent research and development.

Global Impact: From the bustling streets of Beijing to the far corners of the globe, Shenzhou Anfu’s influence is far-reaching. We are a trusted partner in security for industries spanning banking, finance, e-government, and beyond.

Our Promise: At Shenzhou Anfu, we believe in a future where security is not just a feature, but a guarantee. With leading technology, scientific decision-making, and standardized management, we are more than just a company – we are your partner in progress.

Join Us:

Step into a world where your security is our priority. Experience the Shenzhou Anfu difference. Together, let's unlock the future.



Specification



Function Describe
Processor Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz


Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency

96MHz

Memory Main CPU: 16MB Flash, 16MB RAM
Display 2.4 "(320 × 240) TFT, resistive touch screen
RTC Built in RTC to save the clock; Button battery life > 5 years
Signature pen Touch screen handwriting signature pen, plug-in
Key

20 physical keys: 1 power key, 12 digit / letter keys and 7 function

keys,Cancel, clear, F1 / F2 / F3, menu)

Contact IC card

Comply with ISO 7816 and China financial integrated circuit (IC) card

specification;

The card holder can be used for more than 300000 times

Contactless card

13.56MHz;

Support iso14443 type A & B standard;

Qpboc compliant

Magnetic stripe

card



Support three track data reading;

It supports two-way card swiping. The swiping speed ranges from 10

cm / s to 100 cm / s. The service life of the magnetic stripe reader

can reach more than 400000 times;

It conforms to iso7811

Camera(optional)

Built in 300 megapixel camera

Support bar code, two-dimensional code scanning

Printer

High speed thermal printing, printing life is not less than 50km

The specification is 58mm in width and 40mm in diameter

mobile

communication

FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40

GSM:B2/B3/B5/B8 (Recommended: South America)



FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41

GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa)

Wifi(optional) 802.11 a/b/g/n,2.4G
Bluetooth (optional) BLE 4.0 and above
Card slots 1 SIM + 2 SAMs | 2 SIMs + 1 SAM
External interface 1 TYPE-C USB,For charging and serial communication
Battery(Optional) 3.7V,2500mAh 3.7V,3000mAh
Buzzer Support
Indication light 1 power indicator + 4 contactless indicator
Physical size 177mm*81mm*56mm
Weight 340g
Certificate

PBOC3.0 L1&L2

EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED

UPTS2.0 Security assessment of UnionPay terminal

Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American

ExpressPay

SRRC/CTA/TQM3CCEBISWPC





Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function 0Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function 1Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function 2



Real Case for Lower MOQ:

Products Name MOQ(in the last 12month)
POS Device 5 Pieces

The competitive advantage of product line:

Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.



Certificate



Portable Handheld POS LINUX 2.4 Inch Touch Screen NFC Pos Terminal with EMV card swiping payment function 3



FAQ



1. Q: How can I get the touch pos terminal sample to check quality?

After price comfirmation, you can order pos samples to check quality.

Contact:whatsapp +86 18011965815



2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,



3. Q: How can I become your agent?

A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.



4. Q: Who will pay the postage of the returns?

A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)



5. Q:What is your warranty?

We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
