Product Details:
|
Exceptional Functions: | Supports For All Types Of Payment | Cpu: | ARM Cortex-A5, Maximum Clock Frequency 500MHz |
---|---|---|---|
Barcode Recognition: | Suppor 1D 2D | Customize: | Yes |
Products Status: | Stock | Battery Capacity: | 3.7V,2500mAh 3.7V,3000mAh |
Currency: | USD.EURO.CNY | Max Paper Size: | 58mm |
Company Information
Imagine a world where your security is as seamless as a fingerprint, where every transaction is shielded by an invisible fortress, and your digital life is safeguarded by technology so advanced, it feels like magic. Welcome to Shenzhou Anfu – where cutting-edge innovation meets unwavering trust.
Who We Are: At the heart of Beijing, Shenzhou Anfu stands as a beacon of excellence in the realm of security technology. Our mission is simple yet profound: to protect what matters most to you with unparalleled precision and reliability.
Our Credentials: Certified and celebrated, Shenzhou Anfu is recognized as a National High-Tech Enterprise. We proudly hold the ISO 9001:2015 certification, among other prestigious accolades, underscoring our commitment to quality and innovation.
Innovation at Our Core: Dive into our world, built on a foundation of relentless research and development. Our 32-bit embedded high-performance CPU SOC chip design platform is not just technology – it’s the future of security. From information security to mobile payments, our SOC chip products are designed to meet the demands of a fast-evolving digital landscape.
Versatile and Visionary: Our products find homes in smart locks, intelligent terminals, financial payment systems, and more. Imagine your home, your transactions, and your data, all protected by Shenzhou Anfu’s cutting-edge technology. We don't just create products; we create peace of mind.
Intellectual Prowess: With 14 independent intellectual property rights, including invention and utility model patents, our innovations speak for themselves. Each product is a testament to our dedication to independent research and development.
Global Impact: From the bustling streets of Beijing to the far corners of the globe, Shenzhou Anfu’s influence is far-reaching. We are a trusted partner in security for industries spanning banking, finance, e-government, and beyond.
Our Promise: At Shenzhou Anfu, we believe in a future where security is not just a feature, but a guarantee. With leading technology, scientific decision-making, and standardized management, we are more than just a company – we are your partner in progress.
Step into a world where your security is our priority. Experience the Shenzhou Anfu difference. Together, let's unlock the future.
Specification
Function | Describe |
Processor | Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz |
Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency 96MHz |
|
Memory | Main CPU: 16MB Flash, 16MB RAM |
Display | 2.4 "(320 × 240) TFT, resistive touch screen |
RTC | Built in RTC to save the clock; Button battery life > 5 years |
Signature pen | Touch screen handwriting signature pen, plug-in |
Key |
20 physical keys: 1 power key, 12 digit / letter keys and 7 function keys,Cancel, clear, F1 / F2 / F3, menu) |
Contact IC card |
Comply with ISO 7816 and China financial integrated circuit (IC) card specification; The card holder can be used for more than 300000 times |
Contactless card |
13.56MHz; Support iso14443 type A & B standard; Qpboc compliant |
Magnetic stripe card
|
Support three track data reading; It supports two-way card swiping. The swiping speed ranges from 10 cm / s to 100 cm / s. The service life of the magnetic stripe reader can reach more than 400000 times; It conforms to iso7811 |
Camera(optional) |
Built in 300 megapixel camera Support bar code, two-dimensional code scanning |
Printer |
High speed thermal printing, printing life is not less than 50km The specification is 58mm in width and 40mm in diameter |
mobile communication |
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40 GSM:B2/B3/B5/B8 (Recommended: South America) |
FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41 GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa) |
|
Wifi(optional) | 802.11 a/b/g/n,2.4G |
Bluetooth (optional) | BLE 4.0 and above |
Card slots | 1 SIM + 2 SAMs | 2 SIMs + 1 SAM |
External interface | 1 TYPE-C USB,For charging and serial communication |
Battery(Optional) | 3.7V,2500mAh 3.7V,3000mAh |
Buzzer | Support |
Indication light | 1 power indicator + 4 contactless indicator |
Physical size | 177mm*81mm*56mm |
Weight | 340g |
Certificate |
PBOC3.0 L1&L2 EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED UPTS2.0 Security assessment of UnionPay terminal Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American ExpressPay SRRC/CTA/TQM3CCEBISWPC |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
