Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner

Certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
I'm Online Chat Now

Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner

Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner
Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner

Large Image :  Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner

Product Details:
Place of Origin: China
Brand Name: Shenzhou Anfu
Certification: ISO,Test Report
Model Number: AF70
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: US$45-55/pc
Packaging Details: one piece to a small box , 10pcs to a carton box
Delivery Time: 2-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000-40000/Month

Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner

Description
Wireless: 2G/3G/4G Screen Size: 2.4 Inch
Comprehensive Adaption: Supports For Bluetooth Hard Disk Capacity: 8GB
Monthly Supply Ability: 20000 -40000Sets/Month Connectivity: WiFi, Bluetooth, 3G, 4G
Sample Sending Date: 7 Days Scanner: 1D&2D Barcode Scanner (optional)
High Light:

Optional Barcode Scanner POS

,

2.4 inch Handheld POS

,

4G Wifi Thermal Printer POS

2.4”POS Handheld Code Scanner Handheld Mobile RTOS Pos Mini Portable Cash Register 4G Wifi 58mm Thermal Printer



Company Information



Shenzhou Anfu is a distinguished high-tech enterprise that specializes in the design, development, and sales of security SOC (System on Chip) chips and modules, along with a wide range of security terminal products. Headquartered in Beijing, the company has established itself as a leader in the security technology sector through its innovative approach and dedication to quality.

Core Competencies and Certifications:

  • Certifications: Shenzhou Anfu holds several prestigious certifications, including the National High-Tech Enterprise Certification, UnionPay Card Acceptance Terminal Product Enterprise Certification, Software Enterprise Certification, and ISO 9001:2015 Quality Management System Certification. Additionally, it is authorized by the State Password Administration for the production and sales of commercial password products.

  • Technological Focus: The company focuses on foundational research and development in security, leveraging a 32-bit embedded high-performance CPU SOC chip design platform. This platform supports the creation of a variety of information security and mobile payment SOC chip products and applications.

Product and Service Offerings:

Shenzhou Anfu's products are widely deployed across several sectors:

  • Intelligent Terminals
  • Security Protection Products
  • Smart Home Systems
  • Smart Locks
  • Financial Payment Solutions
  • Specialized Information Encryption Products

Intellectual Property and Innovation:

  • Patents and Rights: The company has acquired 14 independent intellectual property rights, which include 2 invention patents, 5 utility model patents, 4 design patents, and 9 software copyrights.
  • Research and Development: Committed to independent R&D, Shenzhou Anfu invests heavily in product research and design each year. This investment has enabled the serial production of the AX200 chip products and the development of multiple industry-specific security solutions.

Market Position and Impact:

Through its leading technology, scientific decision-making, and standardized management, Shenzhou Anfu has emerged as a well-known entity in the field of security encryption. It serves as a key supplier of security chips, modules, and intelligent security terminals in sectors such as:

  • Security
  • Banking and Finance
  • E-Government
  • Convenience Services

Global Reach:

Shenzhou Anfu's influence extends beyond China, providing its advanced security solutions to both domestic and international markets. The company's continuous innovation and commitment to quality ensure its position as a trusted provider in the rapidly evolving security technology landscape.



Specification



Function Describe
Processor Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz


Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency

96MHz

Memory Main CPU: 16MB Flash, 16MB RAM
Display 2.4 "(320 × 240) TFT, resistive touch screen
RTC Built in RTC to save the clock; Button battery life > 5 years
Signature pen Touch screen handwriting signature pen, plug-in
Key

20 physical keys: 1 power key, 12 digit / letter keys and 7 function

keys,Cancel, clear, F1 / F2 / F3, menu)

Contact IC card

Comply with ISO 7816 and China financial integrated circuit (IC) card

specification;

The card holder can be used for more than 300000 times

Contactless card

13.56MHz;

Support iso14443 type A & B standard;

Qpboc compliant

Magnetic stripe

card



Support three track data reading;

It supports two-way card swiping. The swiping speed ranges from 10

cm / s to 100 cm / s. The service life of the magnetic stripe reader

can reach more than 400000 times;

It conforms to iso7811

Camera(optional)

Built in 300 megapixel camera

Support bar code, two-dimensional code scanning

Printer

High speed thermal printing, printing life is not less than 50km

The specification is 58mm in width and 40mm in diameter

mobile

communication

FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40

GSM:B2/B3/B5/B8 (Recommended: South America)



FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41

GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa)

Wifi(optional) 802.11 a/b/g/n,2.4G
Bluetooth (optional) BLE 4.0 and above
Card slots 1 SIM + 2 SAMs | 2 SIMs + 1 SAM
External interface 1 TYPE-C USB,For charging and serial communication
Battery(Optional) 3.7V,2500mAh 3.7V,3000mAh
Buzzer Support
Indication light 1 power indicator + 4 contactless indicator
Physical size 177mm*81mm*56mm
Weight 340g
Certificate

PBOC3.0 L1&L2

EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED

UPTS2.0 Security assessment of UnionPay terminal

Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American

ExpressPay

SRRC/CTA/TQM3CCEBISWPC





Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner 0Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner 1Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner 2



Real Case for Lower MOQ:

Products Name MOQ(in the last 12month)
POS Device 5 Pieces

The competitive advantage of product line:

Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.



Certificate



Portable 2.4 inch Handheld POS with 4G Wifi Thermal Printer and Optional Barcode Scanner 3



FAQ



1. Q: How can I get the touch pos terminal sample to check quality?

After price comfirmation, you can order pos samples to check quality.

Contact:whatsapp +86 18011965815



2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,



3. Q: How can I become your agent?

A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.



4. Q: Who will pay the postage of the returns?

A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)



5. Q:What is your warranty?

We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
