Product Details:
|
Operating System: | RTOS,LINUX | Function: | 3g/wifi/bluetooth/scanner/printer |
---|---|---|---|
Network: | 2/3/4G | Max Paper Size: | 58MM |
Trial Order: | Available | Wireless Connection: | Connects With Mobile Phone Via Bluetooth |
Software: | SDK/APK | Card Type: | NFC&IC |
High Light: | Barcode Scanner Mobile Pos Terminal,handheld linux RTOS pos machine |
Company Information
Shenzhou Anfu is a leading high-tech enterprise based in Beijing, specializing in the development, design, and sales of security System on Chip (SOC) solutions and security terminal products. The company is renowned for its innovative approach and commitment to quality in the security technology sector.
Shenzhou Anfu focuses on cutting-edge research and development, particularly in the field of security. The company utilizes a 32-bit embedded high-performance CPU SOC chip design platform to create advanced information security and mobile payment solutions.
Shenzhou Anfu's products are widely used in various sectors, including:
Patents and Intellectual Property:
Research and Development: The company is dedicated to independent R&D, investing heavily in product innovation each year. This commitment has led to the serial production of AX200 chip products and the development of multiple industry-specific security solutions.
With leading-edge technology, strategic decision-making, and standardized management, Shenzhou Anfu has become a well-known name in the security encryption field. The company is a reliable supplier of security chips, modules, and intelligent security terminals, serving various sectors such as:
Shenzhou Anfu's innovative security solutions have a broad international presence, serving clients both domestically and abroad. The company's ongoing commitment to quality and technological advancement ensures its position as a top-tier provider in the security technology industry.
By focusing on research, innovation, and quality, Shenzhou Anfu continues to lead the way in providing advanced security solutions to meet the evolving needs of various industries worldwide.
Specification
Function | Describe |
Processor | Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz |
Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency 96MHz |
|
Memory | Main CPU: 16MB Flash, 16MB RAM |
Display | 2.4 "(320 × 240) TFT, resistive touch screen |
RTC | Built in RTC to save the clock; Button battery life > 5 years |
Signature pen | Touch screen handwriting signature pen, plug-in |
Key |
20 physical keys: 1 power key, 12 digit / letter keys and 7 function keys,Cancel, clear, F1 / F2 / F3, menu) |
Contact IC card |
Comply with ISO 7816 and China financial integrated circuit (IC) card specification; The card holder can be used for more than 300000 times |
Contactless card |
13.56MHz; Support iso14443 type A & B standard; Qpboc compliant |
Magnetic stripe card
|
Support three track data reading; It supports two-way card swiping. The swiping speed ranges from 10 cm / s to 100 cm / s. The service life of the magnetic stripe reader can reach more than 400000 times; It conforms to iso7811 |
Camera(optional) |
Built in 300 megapixel camera Support bar code, two-dimensional code scanning |
Printer |
High speed thermal printing, printing life is not less than 50km The specification is 58mm in width and 40mm in diameter |
mobile communication |
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40 GSM:B2/B3/B5/B8 (Recommended: South America) |
FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41 GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa) |
|
Wifi(optional) | 802.11 a/b/g/n,2.4G |
Bluetooth (optional) | BLE 4.0 and above |
Card slots | 1 SIM + 2 SAMs | 2 SIMs + 1 SAM |
External interface | 1 TYPE-C USB,For charging and serial communication |
Battery(Optional) | 3.7V,2500mAh 3.7V,3000mAh |
Buzzer | Support |
Indication light | 1 power indicator + 4 contactless indicator |
Physical size | 177mm*81mm*56mm |
Weight | 340g |
Certificate |
PBOC3.0 L1&L2 EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED UPTS2.0 Security assessment of UnionPay terminal Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American ExpressPay SRRC/CTA/TQM3CCEBISWPC |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
