Product Details:
|
Style: | Black (Customized) | Barcode Scanner: | Optional,(1D&2D) |
---|---|---|---|
Interface Type: | Bluetooth/USB | Connectivity: | WiFi, Bluetooth, 4G LTE |
Touch Panel: | Capacititve Touch | Oem: | Acceptable |
Wireless Connection: | WIFI 4G | Item: | Handheld POS Terminal |
High Light: | 58mm Handheld POS Terminal,4G NFC Portable RTOS Pos Machine,4G Handheld POS Terminal |
Company Information
We are Shenzhou Anfu, a global leader in the design, development, and sales of cutting-edge security SOC chips and modules, as well as innovative security terminal products. Our commitment to excellence has earned us several prestigious certifications, including the National High-Tech Enterprise Certification, UnionPay Card Acceptance Terminal Product Enterprise Certification, Software Enterprise Certification, and ISO9001:2015 Quality Management System Certification. Additionally, we are an officially designated production and sales unit for commercial password products approved by the State Password Administration.
At Shenzhou Anfu, we are dedicated to pioneering advancements in security technology. Our expertise is built on a robust 32-bit embedded high-performance CPU SOC chip design platform, which underpins our extensive range of SOC chip products and application programs focused on information security and mobile payment. Our comprehensive solutions include:
These solutions are widely utilized across various sectors, including intelligent terminals, security protection products, smart homes, smart locks, financial payment systems, and specialized information encryption products.
Innovation is at the heart of Shenzhou Anfu. We proudly hold 14 independent intellectual property rights, including:
We adhere to a philosophy of independent research and development, investing heavily in product research and design each year. This commitment has led to the successful serial production of the AX200 chip series and the launch of numerous industry-specific security solutions.
With our leading technology, strategic decision-making, and standardized management, Shenzhou Anfu has become a renowned name in the field of security encryption. We serve as a key supplier of independent security chips and modules, as well as intelligent security terminals, catering to sectors such as security, banking and finance, e-government, and convenience services worldwide.
Join us at Shenzhou Anfu as we continue to drive the future of security technology. Together, we can build a safer, smarter, and more secure world.
Specification
Function | Describe |
Processor | Main CPU: ARM Cortex-A5, maximum clock frequency 500MHz |
Security CPU: 32 bit, ARM Cortex-M0, maximum clock frequency 96MHz |
|
Memory | Main CPU: 16MB Flash, 16MB RAM |
Display | 2.4 "(320 × 240) TFT, resistive touch screen |
RTC | Built in RTC to save the clock; Button battery life > 5 years |
Signature pen | Touch screen handwriting signature pen, plug-in |
Key |
20 physical keys: 1 power key, 12 digit / letter keys and 7 function keys,Cancel, clear, F1 / F2 / F3, menu) |
Contact IC card |
Comply with ISO 7816 and China financial integrated circuit (IC) card specification; The card holder can be used for more than 300000 times |
Contactless card |
13.56MHz; Support iso14443 type A & B standard; Qpboc compliant |
Magnetic stripe card
|
Support three track data reading; It supports two-way card swiping. The swiping speed ranges from 10 cm / s to 100 cm / s. The service life of the magnetic stripe reader can reach more than 400000 times; It conforms to iso7811 |
Camera(optional) |
Built in 300 megapixel camera Support bar code, two-dimensional code scanning |
Printer |
High speed thermal printing, printing life is not less than 50km The specification is 58mm in width and 40mm in diameter |
mobile communication |
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;TDD-LTE:B40 GSM:B2/B3/B5/B8 (Recommended: South America) |
FDD-LTE:B1/B3/B5/B7/B8/B20;TDD-LTE:B38/B40/B41 GSM:B3/B8 (Recommended: Eurasia/Middle East/Africa) |
|
Wifi(optional) | 802.11 a/b/g/n,2.4G |
Bluetooth (optional) | BLE 4.0 and above |
Card slots | 1 SIM + 2 SAMs | 2 SIMs + 1 SAM |
External interface | 1 TYPE-C USB,For charging and serial communication |
Battery(Optional) | 3.7V,2500mAh 3.7V,3000mAh |
Buzzer | Support |
Indication light | 1 power indicator + 4 contactless indicator |
Physical size | 177mm*81mm*56mm |
Weight | 340g |
Certificate |
PBOC3.0 L1&L2 EMV L1&L2,EMV CL L1 PCI PTS 5.X,SRED UPTS2.0 Security assessment of UnionPay terminal Mastercard PayPass ,Visa PayWave ,Discover D-PAS,American ExpressPay SRRC/CTA/TQM3CCEBISWPC |
Products Name | MOQ(in the last 12month) |
POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
