ANFU EMV Magnetic card reader NFC handheld mobile payment pos terminal WITH PCI 6.0 Certified
Company Information
Who We Are:
Shenzhou Anfu is a leading high-tech enterprise specializing in the design, development, and sales of security SOC chips and modules, as well as advanced security terminal products. Our dedication to excellence and innovation has been recognized through several prestigious certifications, including:
- National High-Tech Enterprise Certification
- UnionPay Card Acceptance Terminal Product Enterprise Certification
- Software Enterprise Certification
- ISO9001:2015 Quality Management System Certification
We are also officially designated by the State Password Administration for the production and sales of commercial password products.
What We Do:
Our core focus is on advancing security technology. We have built a robust 32-bit embedded high-performance CPU SOC chip design platform, enabling us to develop a wide range of SOC chip products and application programs tailored to information security and mobile payment needs. Our offerings encompass:
- Design
- Production
- Sales
- Service
Our solutions are extensively used in various fields, including:
- Intelligent terminals
- Security protection products
- Smart homes
- Smart locks
- Financial payment systems
- Specialized information encryption products
Our Achievements:
Shenzhou Anfu is proud to hold 14 independent intellectual property rights, including:
- 2 invention patents
- 5 utility model patents
- 4 appearance patents
- 9 software copyrights
We are committed to independent research and development, investing heavily in product innovation each year. This has led to the successful production of the AX200 chip series and the launch of multiple industry-specific security solutions.
Our Vision:
With our leading technology, strategic decision-making, and standardized management, Shenzhou Anfu has become a well-known name in the field of security encryption. We serve as a key supplier of independent security chips and modules, as well as intelligent security terminals, across various sectors such as security, banking and finance, e-government, and convenience services globally.
Why Shenzhou Anfu?
- Proven Expertise: Decades of experience in security technology and product innovation.
- Certified Quality: Rigorous quality management and multiple high-level certifications.
- Global Reach: Trusted by clients in various industries around the world.
- Commitment to Innovation: Continuous investment in research and development to stay ahead of industry trends.
We invite you to join us at Shenzhou Anfu as we continue to drive the future of security technology. Together, let's build a safer, smarter, and more secure world.
Specification
| Operating System |
Linux 5.4
RTOS |
| Processor |
Linux:Cortex-A7 1.2 GHz
RTOS:Cortex-A5 500MHz
High performance 32-bit security CPU |
| Memory |
Linux:256MB Flash + 128MB RAM
RTOS:8MB Flash + 16MB RAM |
| Card Readers |
MSR: ISO7810-7813, 3 tracks
IC Card: ISO7816 |
| NFC Reader |
13.56MHz, ISO/IEC14443 TypeA&B, |
| Camera |
Rear camera:0.3 million pixels |
| Display |
2.8" 320x240 TFT
Resistive Touch Screen |
| Wireless Communication |
Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS)
RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS) |
| Battery |
emovable Lithium polymer
battery, 3.7V/2500mAh | 3.7V/3200mAh (optional) |
| Printer |
High speed thermal printing, printing lifeis not less than 50km
The specification is 58mm in width and 40mm in diameter |
Card Slots
SIM / SAM |
SIM Card x 2 + PSAM X 1 |
| Positioning |
X |
| Keypad |
Numeric x 10
Function x 8
Power x 1 |
| Audio |
1 Buzzer |
| Ports |
Linux:1 Type-C USB OTG | USB 2.0
RTOS:11 Type-C | USB 2.0 |
| Indicator lights |
4 Work indicator lights |
| Adapter |
Input: AC 100-240V, 50/60Hz
Output: 5V/1A |
| Scanning charging base |
X |
| Weight |
340g |
| Physical size |
177mm*81mm*56mm |
| Environment |
Storage temperature: -20°C to 60°C
Operating temperature: -10°C to 50°C
Humidity: ≤95% |
| Certifications |
EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass
PCI PTS 6.x / TQM / CE |
| Display |
2.8"(320 x 240)TFT, resistive touch screen |
| WlFl(optional) |
802.11 a/b/g/n,2.4G |
| Mobile communication |
Linux:4G CAT4,WCDMA,GSM
RTOS:4G CAT1,GSM
South American Version
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;
TDD-LTE:B40
GSM:B2/B3/B5/B8
European Version
FDD-LTE:B1/B3/B5/B7/B8/B20;
TDD-LTE:B38/B40/B41
GSM:B3/B8 |
| Contact lC card |
Comply with lS0 7816 and China financial
integrated circuit (lC) card specification;
The card holder can be used for more than300000 times |
| Magnetic stripe card |
Support three track data reading;
It supports two-way card swiping.
The swipingspeed ranges from 10 cm /s to 100 cm /s.
The service life of the magnetic stripe reader canreach more than 400000 times;
It conforms to iso78ll and iso7812 standards |
| RTC |
Built in RTC to save the clock; Buttonbattery life > 5 years |
Real Case for Lower MOQ:
| Products Name |
MOQ(in the last 12month) |
| POS Device |
5 Pieces |
The competitive advantage of product line:
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
