Home ProductsMobile POS Terminal

2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV

Certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
China Beijing Shenzhou Anfu Technology Co. Limited certification
I'm Online Chat Now

2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV

2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV
2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV 2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV 2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV 2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV

Large Image :  2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV

Product Details:
Place of Origin: China
Brand Name: Shenzhou Anfu
Certification: ISO,Test Report
Model Number: AF75
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: US$45-55/pc
Packaging Details: one piece to a small box , 10pcs to a carton box
Delivery Time: 2-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000-40000/Month

2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV

Description
Communication: Bluetooth / Wifi Touch Screen: 2.8 Inch
Color: Blue(Customized) OEM: Acceptable
Payment Methods: Credit Card, Debit Card, NFC Built In: 1D/2D Barcode Reader
Connectivity: WiFi/Bluetooth/4G Type: Traditional POS Terminal
High Light:

8G ROM Pos Machine System

,

EMV Pos Machine System

,

2.8 Inch Pos Machine System

2.8 Inch linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal with EMV



Company Information

Welcome to Shenzhou Anfu

At Shenzhou Anfu, we are dedicated to pioneering the future of security technology. Based in Beijing, our company excels in the design, development, and sales of advanced security System on Chip (SOC) solutions and security terminal products. We serve customers around the globe with innovative and reliable security solutions.

Our Expertise

Shenzhou Anfu specializes in creating high-performance SOC chips and security terminal products. Our expertise covers:

  • SOC Chips and Modules: We utilize a 32-bit embedded high-performance CPU SOC chip design platform to develop cutting-edge security solutions.
  • Security Terminal Products: Our products are designed to meet the highest standards of security and performance.

Certifications and Achievements

Our dedication to quality and innovation has earned us several prestigious certifications:

  • National High-Tech Enterprise Certification
  • UnionPay Card Acceptance Terminal Product Enterprise Certification
  • Software Enterprise Certification
  • ISO 9001:2015 Quality Management System Certification

We are also an authorized production and sales unit for commercial password products by the State Password Administration.

Innovative Product Range

Our products are used across various industries, providing robust security solutions for:

  • Intelligent Terminals
  • Security Protection Products
  • Smart Home Devices
  • Smart Locks
  • Financial Payment Solutions
  • Specialized Information Encryption Products

Intellectual Property and R&D

Innovation is at the core of Shenzhou Anfu. We hold 14 independent intellectual property rights, including:

  • 2 Invention Patents
  • 5 Utility Model Patents
  • 4 Design Patents
  • 9 Software Copyrights

We invest heavily in research and development, leading to the serial production of AX200 chip products and the creation of multiple industry-specific security solutions.

Global Market Leadership

Our advanced technology, strategic decision-making, and standardized management practices have positioned Shenzhou Anfu as a leader in the field of security encryption. We are a trusted supplier for sectors including:

  • Security
  • Banking and Finance
  • E-Government
  • Convenience Services

Worldwide Reach

Shenzhou Anfu's innovative security solutions are utilized by clients around the world. Our commitment to quality and continuous innovation ensures we remain at the forefront of the global security technology industry.

Specification





Operating System Linux 5.4
RTOS
Processor Linux:Cortex-A7 1.2 GHz
RTOS:Cortex-A5 500MHz
High performance 32-bit security CPU
Memory Linux:256MB Flash + 128MB RAM
RTOS:8MB Flash + 16MB RAM
Card Readers MSR: ISO7810-7813, 3 tracks
IC Card: ISO7816
NFC Reader 13.56MHz, ISO/IEC14443 TypeA&B,
Camera Rear camera:0.3 million pixels
Display 2.8" 320x240 TFT
Resistive Touch Screen
Wireless Communication Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS)
RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS)
Battery emovable Lithium polymer
battery, 3.7V/2500mAh | 3.7V/3200mAh (optional)
Printer High speed thermal printing, printing lifeis not less than 50km
The specification is 58mm in width and 40mm in diameter
Card Slots
SIM / SAM
SIM Card x 2 + PSAM X 1
Positioning X
Keypad Numeric x 10
Function x 8
Power x 1
Audio 1 Buzzer
Ports Linux:1 Type-C USB OTG | USB 2.0
RTOS:11 Type-C | USB 2.0
Indicator lights 4 Work indicator lights
Adapter Input: AC 100-240V, 50/60Hz
Output: 5V/1A
Scanning charging base X
Weight 340g
Physical size 177mm*81mm*56mm
Environment Storage temperature: -20°C to 60°C
Operating temperature: -10°C to 50°C
Humidity: ≤95%
Certifications EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass
PCI PTS 6.x / TQM / CE
Display 2.8"(320 x 240)TFT, resistive touch screen
WlFl(optional) 802.11 a/b/g/n,2.4G
Mobile communication Linux:4G CAT4,WCDMA,GSM
RTOS:4G CAT1,GSM
South American Version
FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;
TDD-LTE:B40
GSM:B2/B3/B5/B8
European Version
FDD-LTE:B1/B3/B5/B7/B8/B20;
TDD-LTE:B38/B40/B41
GSM:B3/B8
Contact lC card Comply with lS0 7816 and China financial
integrated circuit (lC) card specification;
The card holder can be used for more than300000 times
Magnetic stripe card Support three track data reading;
It supports two-way card swiping.
The swipingspeed ranges from 10 cm /s to 100 cm /s.
The service life of the magnetic stripe reader canreach more than 400000 times;
It conforms to iso78ll and iso7812 standards
RTC Built in RTC to save the clock; Buttonbattery life > 5 years









Real Case for Lower MOQ:

Products Name MOQ(in the last 12month)
POS Device 5 Pieces

The competitive advantage of product line:

Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.



Certificate



2.8 Inch Linux RTOS Pos Machine System 2GB RAM 8G ROM Traditional Pos Terminal With EMV 0



FAQ



1. Q: How can I get the touch pos terminal sample to check quality?

After price comfirmation, you can order pos samples to check quality.

Contact:whatsapp +86 18011965815



2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it shipped,



3. Q: How can I become your agent?

A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.



4. Q: Who will pay the postage of the returns?

A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)



5. Q:What is your warranty?

We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
